Medical Equipment Castors
Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from Colson are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.
381a 40K075v KGD
On request
381a 40K075v KGD 75 mm - 125 mm, 75 kg - 110 kg
Technical data
| Diameter | 75 mm |
| Tread width | 59/2x10 mm |
| Height | 95 mm |
| Threaded stem size | M12x25 mm |
| Load capacity | 75 kg |
Technical description
- plastic castor
- wheels have easy rollability
- the design protects axle / bearing areas from hair / water
- total lock models lock both the wheel and swivel
- also available wheel diameter 125 mm with fixing pin K622 (28x45 mm)
Areas of application
- diagnostic equipment
- electronic equipment
- medical equipment
- care beds
- patient lifts
381a 40K075v KPS
On request
381a 40K075v KPS 75 mm - 125 mm, 75 kg - 110 kg
Technical data
| Diameter | 75 mm |
| Tread width | 59/2x10 mm |
| Height | 105 mm |
| Top plate dimensions | 94X64 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 78/72X45 mm |
| Load capacity | 75 kg |
Technical description
- plastic castor
- wheels have easy rollability
- the design protects axle / bearing areas from hair / water
- total lock models lock both the wheel and swivel
- also available wheel diameter 125 mm with fixing pin K622 (28x45 mm)
Areas of application
- diagnostic equipment
- electronic equipment
- medical equipment
- care beds
- patient lifts
381h 40K075v KGD
On request
381h 40K075v KGD 75 mm - 125 mm, 75 kg - 110 kg
Technical data
| Diameter | 75 mm |
| Tread width | 59/2x10 mm |
| Height | 95 mm |
| Threaded stem size | M12x25 mm |
| Load capacity | 75 kg |
Technical description
- plastic castor
- wheels have easy rollability
- the design protects axle / bearing areas from hair / water
- total lock models lock both the wheel and swivel
- also available wheel diameter 125 mm with fixing pin K622 (28x45 mm)
Areas of application
- diagnostic equipment
- electronic equipment
- medical equipment
- care beds
- patient lifts
381h 40K075v KPS
On request
381h 40K075v KPS 75 mm - 125 mm, 75 kg - 110 kg
Technical data
| Diameter | 75 mm |
| Tread width | 59/2x10 mm |
| Height | 105 mm |
| Top plate dimensions | 94X64 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 78/72X45 mm |
| Load capacity | 75 kg |
Technical description
- plastic castor
- wheels have easy rollability
- the design protects axle / bearing areas from hair / water
- total lock models lock both the wheel and swivel
- also available wheel diameter 125 mm with fixing pin K622 (28x45 mm)
Areas of application
- diagnostic equipment
- electronic equipment
- medical equipment
- care beds
- patient lifts
383q 40K150v K985
On request
383q 40K150v K985 125 mm - 150 mm, 120 kg - 150 kg
Technical data
| Diameter | 150 mm |
| Tread width | 64 mm |
| Height | 175 mm |
| Offset | 40 mm |
| Load capacity | 150 kg |
Wheel
- thermoplastic polyurethane tyre (TPU, Shore A 95)
- free of contact discoloration
- precision ball bearing
Technical description
- plastic housing of polyamide white RAL 9010
- precision ball bearings in the fork head
- suitable for cleaning in disinfecting cubicles
- smooth selection function
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- on inquiry with electrically conductive wheel
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical & diagnostic equipment
- medical-technical equipment
- op beds
- op tables
399a 38K150v KPF-FK (NIMBUS)
On request
399a 38K150v KPF-FK 150 mm, 80 kg
Technical data
| Diameter | 150 mm |
| Tread width | 32 mm |
| Height | 201 mm |
| Offset | 42 mm |
| Top plate dimensions | 95x70 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 75x45/72x52 mm |
| Load capacity | 80 kg |
Technical description
- die-cast aluminium load-bearing housing
- highly polished plastic cover white RAL 9016
- unique design and patented technology
- precision ball bearings in the fork head
Areas of application
- medical equipment
- furniture
399q 38K150v K2351 (NIMBUS)
On request
399q 38K150v K2351 150 mm, 80 kg
Technical data
| Diameter | 150 mm |
| Tread width | 32 mm |
| Height | 188 mm |
| Offset | 42 mm |
| Load capacity | 80 kg |
Technical description
- die-cast aluminium load-bearing housing
- highly polished plastic cover, optionally in white or metallic
- unique design and patented technology
- precision ball bearings in the fork head
- suitable for cleaning in disinfection cabins
- smooth selection function
- integrated selection mechanism with total locking brake "q"
- and direction locking brake "r"
- permanently grease filled in the switch mechanism
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
399q 38K150v K985 (NIMBUS)
On request
399q 38K150v K985 150 mm, 80 kg
Technical data
| Diameter | 150 mm |
| Tread width | 32 mm |
| Height | 188 mm |
| Offset | 42 mm |
| Load capacity | 80 kg |
| Weight | 1500 g |
Technical description
- die-cast aluminium load-bearing housing
- highly polished plastic cover, optionally in white or metallic
- unique design and patented technology
- precision ball bearings in the fork head
- suitable for cleaning in disinfection cabins
- smooth selection function
- integrated selection mechanism with total locking brake "q"
- and direction locking brake "r"
- permanently grease filled in the switch mechanism
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
403a 29K100y K00-2
403a29K100yK00-1 100 mm - 125 mm, 250 kg
Technical data
| Diameter | 100 mm |
| Tread width | 2x30 mm |
| Height | 123,5 mm |
| Offset | 30 mm |
| Stem size | 32 mm |
| Brake swivel radius | 95 mm |
| Load capacity | 250 kg |
Wheel
- TPU-wheels (Shore A 95)
- electrically conductive
Technical description
- Plunger lock castor series 403
- Plastic twin wheel castor
- Precision ball bearings in swivel section and wheel
Areas of application
- Medical equipment, for example OP-tables
CT572 R66a W51 7U (CT Serie/s)
125 mm - 150 mm, 150 kg - 200 kg
Technical data
| Diameter | 125 mm |
| Tread width | 78 mm |
| Wheel width | 2x15 mm |
| Height | 132 mm |
| Offset | 109 mm |
| Stem size | 32x50 mm |
| Load capacity | 150 kg |
Wheel
- Polyurethane tread (95 Sh A)
- Precision ball bearing
- Available also in conductive version
Technical description
- Pressed steel body with double bearing in swivel head (precision ball bearing and thrust ball bearing) for high load capacity
- Dust and splash-proof
- Integrated switching mechanism with central total lock
- Permanent grease filling in the switching mechanism
- Also available with other wheel variants and long stem 28x98 mm
Areas of application
- Intensive care beds
- Hospital beds
- Medical equipment
- Operating theatre beds
- Operating tables
- Nursing beds
