Medical Equipment Castors
Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from Colson are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.
DML-21C-P60 (Serie/s DM)
50 mm, 60 kg
Technical data
| Diameter | 50 mm |
| Tread width | 2x18 mm |
| Hub length | 44 mm |
| Height | 72 mm |
| Offset | 30 mm |
| Top plate dimensions | 60x60 mm |
| Top plate hole diameter | 6,2 mm |
| Dist. between holes | 38x38-48x48 mm |
| Brake swivel radius | 55 mm |
| Load capacity | 60 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Areas of application
- bedside cabinets
- brochure display stands
- computer tables
- display stands
- dustbins
- file carts
- garment stands
- greeting card dispensers
- housekeeping carts
- infusion stands
- newspaper dispensers
- sales stands
- small furniture
- sport equipment
DSF-31C-L10 (Serie/s DS)
75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x25 mm |
| Hub length | 60 mm |
| Height | 99 mm |
| Offset | 31 mm |
| Bolt hole diameter | 10 mm |
| Brake swivel radius | 99 mm |
| Load capacity | 100 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Areas of application
- bedside cabinets
- brochure display stands
- computer tables
- display stands
- dustbins
- file carts
- garment stands
- greeting card dispensers
- housekeeping carts
- infusion stands
- newspaper dispensers
- sales stands
- small furniture
- sport equipment
DSF-31C-P77 (Serie/s DS)
75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x25 mm |
| Hub length | 60 mm |
| Height | 102 mm |
| Offset | 31 mm |
| Top plate dimensions | 77x66 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 61x51/56x46 mm |
| Brake swivel radius | 99 mm |
| Load capacity | 100 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Areas of application
- bedside cabinets
- brochure display stands
- computer tables
- display stands
- dustbins
- file carts
- garment stands
- greeting card dispensers
- housekeeping carts
- infusion stands
- newspaper dispensers
- sales stands
- small furniture
- sport equipment
DSL-31C-L10 (Serie/s DS)
75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x25 mm |
| Hub length | 60 mm |
| Height | 99 mm |
| Offset | 31 mm |
| Bolt hole diameter | 10 mm |
| Brake swivel radius | 70 mm |
| Load capacity | 100 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Areas of application
- bedside cabinets
- brochure display stands
- computer tables
- display stands
- dustbins
- file carts
- garment stands
- greeting card dispensers
- housekeeping carts
- infusion stands
- newspaper dispensers
- sales stands
- small furniture
- sport equipment
DSL-31C-P77 (Serie/s DS)
75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x25 mm |
| Hub length | 60 mm |
| Height | 102 mm |
| Offset | 31 mm |
| Top plate dimensions | 77x66 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 61x51/56x46 mm |
| Brake swivel radius | 70 mm |
| Load capacity | 100 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
EHL
EHR
G41AZ-RF2K080 (367a 29K080r ZLD)
367a 29K080r ZLD 80 mm - 200 mm, 100 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Height | 110 mm |
| Offset | 43,5 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 100 kg |
| Weight | 545 g |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- zinc passivated
- swivel bearing with double ball race
- protected from dust and water spray with plastic seal
- also available with plate PD (77x67 mm)
- also available with bolt hole LC (10,2 mm)
- on inquiry also available with fixing pin Z622 (28x45 mm)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
G41AZ-RU2K080 (367a 29K080v ZLD)
80 mm - 200 mm, 100 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Height | 110 mm |
| Offset | 43,5 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 100 kg |
| Weight | 545 g |
Wheel
- thermoplastic polyurethane tyre (TPU) iron grey RAL 7011 (Shore A 95)
- plastic wheel centre and thread guard silver grey RAL7001
- free of contact discoloration
- precision ball bearing
Technical description
- sheet steel metal housing
- zinc passivated
- swivel bearing with double ball race
- protected from dust and water spray with plastic seal
- also available with plate PD (77x67 mm)
- also available with bolt hole LC (10,2 mm)
- on inquiry also available with fixing pin Z622 (28x45 mm)
Areas of application
- Laundry carts
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchen equipment
- industrial kitchens
- laundry
- medical equipment
- medical-technical equipment
- newspaper dispensers
- occasional carts
- restaurant area
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
- waste containers
G41TZ-RF2K080 (367h 29K080r ZLD)
367h 29K080r ZLD 80 mm - 200 mm, 100 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Height | 110 mm |
| Offset | 43,5 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 100 kg |
| Weight | 630 g |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- zinc passivated
- swivel bearing with double ball race
- protected from dust and water spray with plastic seal
- also available with plate PD (77x67 mm)
- also available with bolt hole LC (10,2 mm)
- on inquiry also available with fixing pin Z622 (28x45 mm)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
