Transport Appliance Castors
The global world of networking is shaping new demands on logistics and the transport business. Mobility is being understood in a new way. Not only across national borders, but in the internal flow of goods. Castors from Colson are solid and reliable components within this agile cycle. They move trolleys, workbenches, switch cabinets, cleaning equipment and other mobile facilities – and have just one goal in the process: to guarantee quality – forever.
505a 18K085v ZPS
505a 18K085v ZPS 85 mm, 700 kg
Technical data
| Diameter | 85 mm |
| Tread width | 85 mm |
| Height | 125 mm |
| Offset | 57 mm |
| Top plate dimensions | 190x170 mm |
| Top plate hole diameter | 16,5 mm |
| Dist. between holes | 150x135 mm |
| Load capacity | 700 kg |
Wheel
- Polyurethane tyre red-orange (Shore A 95)
- bonded on cast wheel centre
- precision ball bearing
Technical description
- heavy steel welded construction with special turntable
- zinc passivated
- pressed ball track above, with tapered roller bearing below
- grease filling and grease nipple in fork head
Areas of application
- containers
- fork lift trucks
- lifting carts
- lifting tables
- lifting platforms
- machine constructions
- heavy transport equipment
